CMP3 Pyranometer

  • ISO 9060 Second Class
  • No change of desiccant for 10 years
  • Low cost radiometer for accurate routine measurements
  • Weatherproof cable connector
  • Easy way of leveling the instrument
  • Two CMP3s can form an albedometer
  • 5 year warranty (*)

Add this product to basket Request information
Share this page

CMP3 Pyranometer

The CMP3 pyranometer is an instrument for measuring the solar irradiance. The thermopile sensor construction measures the solar energy that is received from the total solar spectrum and the whole hemisphere (180 degrees field of view). The output is expressed in Watts per meter square. The CMP3 pyranometer is designed for continuous indoor and outdoor use.

The CMP3 pyranometer (ISO 9060:1990 Second Class) is intended for shortwave global solar radiation measurements in the spectral range from 300 to 2800 nm. The thermopile detector measures irradiance up to 2000 W/m² with response time <18 seconds and typical sensitivity 10 µV/W/m² that varies less than 5 % from -10 ºC to +40 ºC.

Operating temperature range is -40 ºC to +80 ºC and the stability is better than 1 % per year.

The CMP3 pyranometer features a snap-on white sun shield, integrated leveling and a weatherproof connector which is supplied pre-wired with 10 m of signal cable for simple installation. An optional mounting rod and longer cable lengths are available. Two CMP 3s can easily be mounted back-to-back to make a low-cost albedometer.

The Pyranometer does not require any power, it supplies a low voltage of 0 to 20mV in relation to the amount of incoming radiation. When a higher voltage level or a 4 to 20mA signal is required, the AMPBOX is the perfect solution.

(*) This product will need to be registered by the end-user within 6 months of purchase to activate the warranty extension

For instruction on the installation of the CMP3 pyranometer, please watch this video.







Back to productcategory

Specifications

Spectral range (50% points) 300 to 2800 nm
Sensitivity 5 to 20 µV/W/m²
Response time 18 s
Zero offset A < 15 W/m²
Zero offset B < 5 W/m²
Directional response (up to 80° with 1000 W/m² beam) < 20 W/m²
Temperature dependence of sensitivity (-10 ºC to +40 ºC) < 5 %
Operational temperature range -40 °C to +80 °C
Maximum solar irradiance 2000 W/m²
Field of view 180 °

FAQ

Accessories

Accessory Description
CM121B/C Shadow Ring CM121B/C Shadow Ring
More information
To be used with Kipp & Zonen pyranometers, smart pyranometers, pyrgeometers and UV radiometers to shield the instrument from direct radiation. Add To Basket
METEON Data Logger METEON Data Logger
More information
METEON is a hand-held device for use with Kipp & Zonen passive radiometers to display real-time irradiation values and has an integrated data logging function to store up to 3500 samples. METEON will operate for up to 7 weeks on 2 x AA batteries. Add To Basket
LOGBOX SD Data Logger LOGBOX SD Data Logger
More information
LOGBOX SD is a weatherproof data logger specifically designed for use with Kipp & Zonen solar radiometers. It allows the connection of multiple instruments and their temperature sensors. It has a large storage capacity, thanks to the internal memory and a SD memory card. LOGBOX SD can work unattended in remote locations for several months on 4 x AA batteries. Add To Basket
AMPBOX Amplifier AMPBOX Amplifier
More information
AMPBOX is a current loop amplifier for the complete range of solar radiometers. Add To Basket
Adjustable Tilt Radiometer Mounting Kit Adjustable Tilt Radiometer Mounting Kit
More information
Mount a radiometer at a desired solar zenith angle between 0° and 90° to measure tilted global or diffuse radiation. Add To Basket
LOGBOX SE Data Logger LOGBOX SE Data Logger
More information
LOGBOX SE is a weatherproof field data logger with GSM/GPRS communication. Designed for use with Kipp & Zonen solar radiation instruments in a wide range of environments, it can run for weeks on 6 x AA internal batteries. LOGBOX SE has flexible analogue and digital inputs with arithmetic logging functions and is compatible with the Modbus® output of our Smart radiometers. Add To Basket
CVF4 Ventilation Unit CVF4 Ventilation Unit
More information
Ventilating radiometers improves the reliability and accuracy of measurements and reduces maintenance. CVF4 is a high quality ventilation unit designed to be used with the higher performance Kipp & Zonen solar instruments. Add To Basket
